Specifications
| DN (mm) | 32 |
| Approval(s) | Belgaqua approved material |
| Rubber type | EPDM drinking water approved |
| Closing Direction | Clockwise to Close |
| Material | Ductile iron |
| Design Standard(s) | Designed according to EN1074 1-2 and EN1171 |
| Pressure Test(s) | Seat: 1.1 x PN (in bar), Body: 1.5 x PN (in bar). Operation torque test. Hydraulic test according to EN 1074-1 and 2 / EN 12266 |
| Working temperature of rubber | Max. 20°C |
| Connection | Socket Ends |
| Material | Ductile iron |
| Dd (mm) | 40 |
| Description | Dienstkr.DN32 PE40xPE40 EPDM |
Attachments
HANDWHEEL FOR GATE VALVES, DN40-50
Item No.
0805001000
HANDWHEEL FOR GATE VALVES, DN25-50
Item No.
0803216
