Specifications
| DN (mm) | 32 |
| Approval(s) | Approved according to DIN-DVGW Certificate NG-4313BQ0203 |
| Rubber type | NBR rubber |
| Closing Direction | Clockwise to Close |
| Material | Ductile iron |
| Design Standard(s) | Designed according to EN13774 |
| Pressure Test(s) | Seat: 1.1 X PN and 0.5 with air (in bar). Body: 1.5 X PN with water, 1.1 X PN and 0.5 with air (in bar) |
| Working temperature of rubber | -20 °C to max. 60°C |
| Connection | Internal Thread |
| Material | Ductile iron |
| Thread (internal) | 1 1/4" |
| Dd (mm) | 40 |
| Description | SERV. CON VA., NBR-GAS, BSP 5/4"F |
